304L 304 Stainless Steel Pipe ERW Welded Seamless Grade 1.4301 1.4306
Place of Origin | China |
---|---|
Brand Name | DELTA |
Certification | ISO |
Model Number | 304 316L 316Ti 317L 321 310S 309S 347 2205 2507 904L.etc |
Minimum Order Quantity | 500 kgs |
Price | 11000-12000USD/Ton |
Packaging Details | standard packing for export |
Delivery Time | 5 - 12 days based on the quantity |
Payment Terms | T/T, Western Union, L/C |
Supply Ability | 10 Ton per week |

Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProducts | Stainless Steel Seamless Pipe | Grade | 304 304L 316L 316Ti 321317L 2205 2507 310S 347 904L.etc |
---|---|---|---|
Standard | ASTM GB EN | Length | 6m Or Custom Cutting Any Length As Request |
Diameter | DN10 - DN400 | Wall Thickness | SCH10 - XXS Or Unstandard Size |
Type | Seamless Pipe | Service | Cutting, Polishing |
Highlight | 304L 304 stainless steel pipe,304 stainless steel pipe 1.4301,1.4306 304 stainless steel tube |
304/304L Stainless Steel Pipe / ERW Welded Pipe / Seamless Steel Pipe Grade 1.4301 1.4306
304L stainless steel pipe is a hollow long round steel, mainly is widely used in petroleum, chemical, medical, food, light industry, machinery, instrument and other industrial pipeline and mechanical structure parts, etc.
In addition, in bending and torsion strength, the weight is lighter, so it is also widely used to make mechanical parts and engineering structures. It is also used to produce all kinds of conventional weapons, guns and shells.
304L stainless steel pipe with 18Cr-8Ni- low carbon is a low-C 304 steel. Under normal conditions, its corrosion resistance is similar to that of 304 steel, but after welding or stress relief, its resistance to intergranular corrosion is excellent; In the case of heat treatment, it can also maintain good corrosion resistance, and the use temperature is -196℃~800℃.
It is applied to outdoor machines in the chemical, coal, and petroleum industries that require high grain boundary corrosion resistance, heat-resistant parts for building materials, and parts with difficult heat treatment.
304L Stainless Steel Pipe is a variant of 304 stainless steel pipe with lower carbon content and is used where welding is required. The lower carbon content minimizes the precipitation of carbides in the heat-affected zone near the weld, and the precipitation of carbides may cause stainless steel to produce intergranular corrosion (welding erosion) in certain environments.
The forging performance of 304L stainless steel is poor and it is difficult to deform. Due to the work hardening phenomenon, the deformation of the core rod cannot be too large and the heat loss is large. Therefore, it must be molded under multiple fires. If the high temperature and heat preservation stage is not handled well, it will cause roughness. crystal.
Type: | tube | |
Outer Diameter | 6-2500mm, (3/8"-100") | |
Thickness | 0.3-150mm,(SCH10-XXS) | |
Length: | 2000mm, 2500mm, 3000mm, 5800mm, 6000mm,12000mm, etc | |
Standard: | ASTM,AISI,JIS,,GB, DIN,,EN | |
Surface: | pickling , polishing | |
Application: | It is widely used in high-temperature and electric industry, medical devices, construction, chemistry, food industry, agriculture, and ship components. | |
Certification: | ISO, SGS,BV | |
Technique: | Cold Drawn Seamless Tube / Welded pipe | |
Edge: | Mill Edge Slit Edge | |
Quality: | SGS Inspection | |
Grade (ASTM UNS) | 201,304,304L,321,316,316L,317L,347H,309S,310S,904L, | |
S32205,2507,254SMOS,32760,253MA,N08926 | ||
Grade (EN) | 1.4301,1.4307,1.4541,1.4401,1.4404,1.4571,1.4438,1.4539,1.4547, | |
1.4529,1.4562,1.4410,1.4878,1.4845,1.4828,1.4876,2.4858,2.4819 | ||
Supply Ability: | 5000 Ton/Tons per Month | |
Packaging & Delivery | in bundle,plastic bags,thin film,wooden pallet,standard seaworthy export packing or as customer demands | |
20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 24-26CBM | ||
40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 54CBM | ||
40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) 68CBM |
Stock range and specification
WELDED PRODUCT | SEAMLESS PRODUCT |
MPS: 1/8" through 24" | NPS: 1/8" through 12" |
Schedules: 5, 10, 10S, 20, 30, 40, 40S, 80, 80S | Schedules: 5, 10, 40, 80, 160, XXH |
Specifications: ASTM A312, ASME SA312 | Specifications: ASTM A312,ASME SA312 |
Corrosion tested to MIL-P-24691/3 or A262 Practice E
Weight % | C | Mn | P | S | Si | Cr | Ni |
---|---|---|---|---|---|---|---|
304 | .08 | 2.00 | .045 | .030 | 1.00 | 18.0-20.0 | 8.0-11.0 |
304L | .035 | 2.00 | .045 | .030 | 1.00 | 18.0-20.0 | 8.0-13.0 |
Grade | Tensile | ||||
---|---|---|---|---|---|
Ultimate/Min | Yield/Min | Elongation/Min | |||
KSI | MPA | KSI | MPA | % | |
304 | 75 | 515 | 30 | 205 | 35 |
304L | 70 | 485 | 25 | 170 | 35 |
