Alloy Steel Round Bar Grade 30CrNiMo8 Diameter 10 - 350mm Hot Rolled Alloy Steel Rod
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | Alloy 30CrNiMo8 |
| Minimum Order Quantity | 1 Ton |
| Price | 600-885USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Products Name | Alloy Steel Round Bar | Diameter | 10 - 350mm |
|---|---|---|---|
| Length | 6m | Tech | Hot Rolled |
| Service | Cutting | MOQ | 1 Ton |
| Loading Port | Shanghai Port | Standard | ASTM EN GB |
| Highlight | 30CrNiMo8 Alloy Steel Round Bar,Hot Rolled Alloy Steel Round Bar |
||
Product Description
Alloy Steel Round Bar Grade 30CrNiMo8 Diameter 10 - 350mm Hot Rolled Alloy Steel Rod
Products Specification
| Products Name |
Alloy 30CrNiMo8 Steel Round Bar |
| Diameter | 10 - 300mm |
| Length | 6m or custom cutting any length as request |
| Type | Hot Rolled |
| Brand | BAOSTEEL DELTA DONGBEI HUAXI SHAGANG.etc |
| MOQ | 1 Ton |
| Loading Port | Shanghai Port |
| Packing | packing by steel wire rope |
| Deliver time | 5 - 7 days for stock materials |
| Other Grade |
Q195,Q235,10#,20#,35#,45#,Q215,Q345,12Cr1Mov, 15CrMo,304,316,20Cr,40Cr,20CrMo,35CrMo,42CrMo, 40CrNiMo,GCr15,65Mn,50Mn,50Cr,3Cr2W8V,20CrMnTi,5CrMnMo ,30CrNiMo8,34CrNiMo6 |
| Standard | ASTM GB EN DIN |
| Application | Structure and Industrial |
Regular Standard Size of our 30CrNiMo8 Round Bar in Stock
| Standard Diameter | 10 12 15 18 20 25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100 105 110 120 130 140 150 160 180 200 210 220 230 250 270 300 320 330 350mm |
The 30CrNiMo8 type of steel is made mostly for forming into wrought products. It is considered a structural steel and has medium hardenability yet it can accommodate heavy-duty components. It offers high elasticity and strength properties and when it is softened, the hardness level reaches a maximum of 248 HRB. It has a lot of resistance to various impacts and loads, but it is not all that great for welding. It also generally requires additional preheating before you can truly do anything with it.
Grade and Standard Specification:
| Grade : | 30CrNiMo8 |
| Number: | 1.6580 |
| Classification: | Alloy special steel |
| Standard: | EN 10083-3: 2006 Steels for quenching and tempering. Technical delivery conditions for alloy steels |
| EN 10269: 1999 Steels and nickel alloys for fasteners with specified elevated and/or low temperature properties | |
| EN 10250-3: 2000 Open steel die forgings for general engineering purposes. Alloy special steels | |
| EN 10297-1: 2003 Seamless circular steel tubes for mechanical and general engineering purposes. Non-alloy and alloy steel tubes. Technical delivery conditions |
Chemical composition % of steel 30CrNiMo8 (1.6580): EN 10083-3-2006
| C | Si | Mn | Ni | P | S | Cr | Mo |
| 0.26 - 0.34 | max 0.4 | 0.5 - 0.8 | 1.8 - 2.2 | max 0.025 | max 0.035 | 1.8 - 2.2 | 0.3 - 0.5 |
Mechanical properties of steel 30CrNiMo8 (1.6580)
| Nominal diameter (mm): | to 16 | 16 - 40 | 40 - 100 | 100 - 160 | 160 - 250 | 250 - 330 | 330 - 660 |
| Rm - Tensile strength (MPa) (+QT) | 1250-1450 | 1250-1450 | 1000-1300 | 1000-1200 | 850-1100 | 850 | 800 |
| EU EN |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
China GB |
Russia GOST |
Inter ISO |
| 30CrNiMo8 | 30CrNiMo8 | SNCM431 | 30CND8 | 823M30 | 30Cr2Ni2Mo | 3KH3M3F | 31CrNiMo8 |
Applications of this type of alloy steel include mostly components for automotive and mechanical engineering. Parts have to be designed for optimum toughness or strength to perform economically under severe dynamic stress, and that’s what this type of steel offers its customers.
Forging and Heat Treatment
To forge the 30CrNiMo8 alloy steel, the forming temperature needs to be 1560 to 1920° Fahrenheit. Normalizing temperatures need to be 1560 to 1600° Fahrenheit, and hardening temperatures should be 1000 to 1250° Fahrenheit and followed by an oil quench. Alloy steel manufacturer facilities usually sell these in bars, and they have medium hardenability design to accommodate a variety of products. Manufacturers do a great job, though, of making sure you get just what you need in the end.
