UNS N08904 / 904L Stainless Steel Round Bar Diameter 5 - 350mm Bright Bar / Black Bar
| Place of Origin | China |
|---|---|
| Brand Name | DELTA |
| Certification | ISO |
| Model Number | 201 304 316L 316Ti 317L 321 309S 310S 2205 17-4PH XM-19 |
| Minimum Order Quantity | 500 kgs |
| Price | 2400 - 3500 USD/Ton |
| Packaging Details | standard packing for export |
| Delivery Time | 5 - 12 days based on the quantity |
| Payment Terms | L/C, T/T, Western Union |
| Supply Ability | 20Ton per week |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Shape | Round | Standard | ASTM EN GB JIS |
|---|---|---|---|
| Grade | 201 304 316L 316Ti 309S 310S 317L 321 329 2205 2507.etc | Application | Construction,Industry,surgical Tools,seawater Equipment.,kitchenware |
| Length | Customers' Requirements,5.8m,6m,2m-6m,or As Required | Size | Custom As Request |
| Packing | Standard Seaworthy Package,In Wooden Cases(for FCL/ LCL Shipment) | Service | Cutting, Surface Finishing |
| Highlight | Black Stainless Steel Round Bar,Bright Stainless Steel Round Bar |
||
Product Description
UNS N08904 / 904L Stainless Steel Round Bar Diameter 5 - 350mm Bright Bar / Black Bar
| Products | Stainless Steel Bar |
| Grade | 904L |
| Diameter | 5 - 350mm |
| Length | 6m or custom cutting any length as request |
| Finishing | Bright Bar / Black Surface |
| Heat Treatment | Solid Solution , ageing |
| Surface Process | Polishing , Peeling |
| Other Grade |
201 303 304 304L 309S 310S 316L 316Ti 317L 321 347 410 420 430 431 2205 2507 904L 254SMO 416 431 440A/B/C.etc |
| MOQ | 500 Kgs |
| Loading Port | Shanghai Port |
| Processing | Cutting |
| Packing | Wooden box or wrapping by PP bag |
904L stainless steel bar
904L stainless steel consists of chromium, nickel, molybdenum and copper contents, these elements give type 904L stainless steel excellent properties to resist corrosion in dilute sulfuric acid because of addition of copper, 904L commonly is used in high pressure and corrosion environment where 316L and 317L perform poorly.
904L has high nickel composition with low carbon content, copper alloy adding improve its resistance to corrosion, the “L” in 904L stands for low carbon, it is typical Super Austenitic stainless steel, equivalent grades are DIN 1.4539 and UNS N08904, 904L has better properties than other austenitic stainless steels.
904L Stainless Steel Chemical Composition (Max %):
| Grade | Ni | Cr | Mo | Cu | C | Mn | Si | P | S | Fe |
| 904L | 23 – 28 | 19 – 23 | 4 -5 | 1 – 2 | 0.02 | 2 | 1 | 0.045 | 0.035 | Balance |
904L Stainless Steel Mechanical Properties
| Grade | Tensile Strength, Min | Yeild Strength, Min | Elognation | Hardness |
| 904L | 490 Mpa | 215 Mpa | 35% | 90 HRB Max |
904L Stainless Steel Properties
- Excellent resistance to stress corrosion cracking due to the presence of high amounts of nickel content.
- Pitting and crevice corrosion, intergranular corrosion resistance.
- Grade 904L is less resistant to nitric acid.
- Excellent formability, toughness and weldability, due to low carbon composition, it can be welded using any standard method, 904L cannot be hardened by heat treatment.
- Non-magnetic, 904L is an Austenitic stainless steel, therefor 904L possesses Austenitic structure properties.
- Heat Resistance, Grade 904L stainless steels offer good oxidation resistance. However, the structural stability of this grade collapses at high temperatures, particularly above 400°C.
- Heat Treatment, Grade 904L stainless steels can be solution heat-treated at 1090 to 1175°C, following by rapid cooling. Thermal treatment is suitable for hardening these grades.
904L Stainless Steel Applications
Because of above properties, 904L stainless steel pipe can be used in many applications, these range from utility scrubber assemblies to acid and fertilizer production equipment, pulp and paper processing, seawater cooling facilities. Used in processes containing sulfuric or phosphoric acids, 904L displays its excellent resistance to corrosion from those acids. The paper, gas, pharmaceutical and chemical industries also use 904L for its resistance and use to 400-450 degrees C. Alloy 904L tubing can be welded, machined, heat treated, annealed, hardened and cold worked for many purposes.
- Petroleum and petrochemical equipment, for example: Reactor
- Storage and transportation equipment of sulphuric acid, for example: heat exchanger
- Sea water treatment equipment, sea water heat exchanger
- Paper industry equipment, sulfuric acid, nitric acid equipment, making acid, pharmaceutical industry
- Pressure vessel
- Food equipment
